Polarizing microscope (PM series)
ItemNo: PM-001B
With the features of streamline and stable frame,easy operation and complete functions,polarizing microscope PM is the best choice for user to observe mineral crystal figure,color and also exactly identify the optical performance of mineral and other crystal specimen
| Specifications | |
| Viewing head | Sliding binocular head at 45º ,360º rotatable |
| Eyepiece | Eyepiece WF10X/18 |
| Objective | Strainfree achromatic objective 4X,10X,40X |
| Nosepiece | Toward quadruple nosepiece |
| Analyzer | Rotatable analyzer with gradution 0 -90º |
| Bertrand lens | Bertrand lens,sliding in / out of optical path |
| Optical compensator | λ Slip(first class red) |
| 1/4λ Slip | |
| Quartz wedge | |
| Revolving round stage | Diameter Φ 135mm,360º rotatable and graduated in 1º Increments, Minimum resolution 6 ,when using vernier scale,center adjustable |
| Condenser | ABBE condenser with lris diaphragm filter |
| Focusing | Coarxial coarse and fine adjustment,range 28mm,fine division 0.002 |
| Polarizer | Sliding in/out of optical path,located on the top of collector |
| Illumination | 110V or 220V/6V20W halogen lamp,brightness adjustable |
