Biological Microscope (BM series)
This series is widely used in Biology, Histology, Medicament chemistry reseach and Clinical examination and education.
ItemNo: BM-009B
| Specifications | Model | ||
| BM-009B | BM-009C | ||
| Objective | WF10X(18mm),WF16X(13mm) | O | O |
| Viewing head | Compensation free binocular head at 30 ,360 rotatable | O | |
| Stage | Double layers mechanical stage 155x142mm/175x50mm | O | O |
| Condenser&Diaphragm | |||
| ABBE N.A.1.25 lris diaphragm and filter | O | O | |
| Focusing | |||
| Coaxial coarse and fine adjustment,focusing range 30mm,focusing interval 0.002mm | O | O | |
| lllumination | |||
| Built-in illumination,halogen lamp 110Vor220V/6V20W | O | O | |
| Optional | Sliding binocular head.Plan achromatic objectives,Quintuple Nosepiece,Turret Annular Phase Contrast Kit MFDCE series digital camera,Dark-field condeser(dry) ,Dark-field condenser(wet) |
||
