Biological Microscope       (BM series)

This series is widely used in Biology, Histology, Medicament chemistry reseach and Clinical examination and education
ItemNo: BM-021B

Categories: ,
Specifications
Eyepiece  WF10X
Objective 45mm achromatic objective:
4X,10X,40X(S),100X(S,Oil)
Viewing head Compensation Free binocular head,
30º lnclined,360º rotatable
Stage Double layers mechanical stage:
130X140mm,Moving range X-Y:50X70mm
Diaphragm Φ2-Φ30mm lris diaphragm and filter
Condenser ABBE condenser:N.A.1.25
Focusing Coaxial coarse and fine focusing
adjustable mechanism:35mm
Illumination Built-in adjustable bringtness halogen lamp
110Vor220V/6V20W,Kohler lllumination
Package Foamed plastic+ carton
Optional Eyepiece WF16X Incandescent Lamp 20W,5W Fluorescent Lamp,LED Lamp,CCD Video Camera,Accessories For Photography
