Polarizing microscope      (PM series)

ItemNo: PM-003C
With the features of streamline and stable frame,easy operation and complete functions,polarizing microscope PM is the best choice for user to observe mineral crystal figure,color and also exactly identify the optical performance of mineral and other crystal specimen

Specifications
Viewing head Trinocular head inclined at 30º ,360º rotatable
Eyepiece Eyepiece WF10X/18
Objective Strainfree achromatic objective 4X,10X,25X(S),40X(S),63X(S)
Nosepiece Toward quadruple nosepiece
Analyzer Rotatable analyzer with gradution 0 -90º
Bertrand lens Bertrand lens,sliding in / out of optical path
Optical compensator λ Slip(first class red)
1/4λ Slip
Quartz wedge
Revolving round stage Diameter Φ 160mm,360º rotatable and graduated in 1º Increments,
Minimum resolution 6 ,when using vernier scale,center adjustable
Condenser ABBE condenser with lris diaphragm filter
Focusing Coarxial coarse and fine adjustment,range 28mm,fine division 0.002
Polarizer Sliding in/out of optical path,located on the top of collector
Illumination Halogen tungsten bulb 85V-230V/12V30W adjustable brightness
