Biological Microscope         (BM series)

This series is widely used in Biology, Histology, Medicament chemistry reseach and Clinical examination and   education
ItemNo: BM-016C

Categories: ,
           Specifications
Eyepiece WF10X
Objective 45mm achromatic objective:
4X,10X,40X(S),100X(S,Oil)
Viewing head Compensation free trinocular head,30º
lnclined,360º rotatable.The vertical
tube is used for second viewing or
connecting with camera
Stage Double layers mechanical stage:
140X155mm,Moving range X-Y:50X70mm
Diaphragm Φ2-Φ30mm lris diaphragm and filter
Condenser ABBE condenser:N.A.1.25
Focusing Coaxial coarse and fine focusing
adjustable mechanism:35mm
Illumination Built-in adjustable bringtness halogen lamp 110Vor120V/6V20W
Package Foamed plastic+ carton
Optional Eyepiece WF16X Incandescent Lamp 20W,5W Fluorescent Lamp,LED Lamp,CCD Video Camera,Accessories For Photography
Turret Annular Phase Contrast Kit
